New 2025 Coachmen RV Catalina Summit Series 7 134RDX
Travel Trailer
Stock # 9017
Minivan Towable!
Specifications
Sleeps
3
Length
16 ft
Ext Width
7 ft 6 in
Ext Height
9 ft 10 in
Interior Color
DRIFTWOOD
Hitch Weight
296 lbs
GVWR
3950 lbs
Dry Weight
2729 lbs
Cargo Capacity
1221 lbs
Fresh Water Capacity
44 gals
Grey Water Capacity
30 gals
Black Water Capacity
30 gals
Furnace BTU
19 btu
Available Beds
2
Refrigerator Type
12 VOLT
Refrigerator Size
3 cu ft
Cooktop Burners
2
Shower Size
24X32
Number of Awnings
1
LP Tank Capacity
20
Water Heater Capacity
6 gal
Water Heater Type
GAS/ELECTRIC
AC BTU
13 btu
Awning Info
8'
Axle Count
1
Number of LP Tanks
1
Shower Type
Walk-In Shower
Electrical Service
30 amp
VIN
5ZT2CABC7SK009815
See All Specs
Description
Electric Awning w/Multicolor LED Strip & Remote
Black Tank Flush
Battery Disconnect Switch
Siphon 360 Holding Tank Roof Vent
Heavy Duty Standard Tongue Jack
(1) 20 lb. LP Tanks
Flush Mount Baggage Doors w/Radius Corners
Diamond Plate Rock Guard
Stabilizer Jacks
G20 Tinted Privacy Windows
Premium JBL Exterior Speaker
Friction Hinged Black Glass Entry Door with Window (Black Glass, Window N/A 134 Series)
Exterior 110V G.F.C.I Protected Receptacle
Exterior RG-6 Coax Cabling and Satellite Prep
Rain Gutters with Drip Spouts
MORryde StepAbove Solid Steps
Rear View Camera Prep
Pets - "Leash Link" Quick Hookup D-Ring
Universal Solar Prep w/Roof & Chg. Contoller Connections & Wiring
Rear Ladder Prep
ator (3.3 Cu. Ft. 12V Refrigerator 134X,154X,164X Series)
Seamless Thermofoil Countertops Throughout
Deep Basin Farm Style Sink
High Rise Bullet Style Kitchen Faucet
GE Stainless 2-Burner Cooktop with Metal Back-Lit Knobs
Range Hood
Paper Towel Holder
GE Stainless Microwave W/Glass Turn Table
Congoleum Woodplank Linoleum Flooring
4000 Lumin LED Interior Touch Lighting
Jiffy Sofa w/Flip Down Cup Holder/Arm Rest (Per Floorplan)
Hard Valance Window Treatments
Pedestal Thermofoil Dinette Table (134RDX, 154RDX, 184BHS, 184BHSX)
Under Bench Dinette Storage (Per Floorplan)
12V 14" Bathroom Power Vent Fan
Marine Toilet with Foot Flush
Mirror
Bedroom Surface Mounts USB Ports (Each Night Stand)
Kitchen USB's & Outlets
Master Bedroom Overhead Shelf
Designer Fitted Master Bed Sheet
Full Lino in Slide-Outs and Bedrooms (Carpetless)
Shower/Coat Hooks
GE 13,500 BTU Central A/C with Heat Pump
Cambered Structural Steel I-Beam Frame
Norco Electromagnetic, Powder Coated Chassis
Full Length Frame Outriggers
5/8" Tongue & Groove StableDeck Flooring
2"x2" Floor Joists on Approximately 12" Centers
4" Floor To Frame Steel Lag Bolts
Darco Subfloor Protective Wrap/Enclosure
Seamless Alpha Roof Membrane with Lifetime Warranty
Cross-Braced Engineered Roof Trusses w/5" Crown
3/8" Fully Decked Walk-On Roof
Screwed Cabinet Construction w/Pocket Bored Lumber Core Stiles
5/8" Plywood Under Bunks & Dinette Base
78" Interior Height (6'6")
R-7 Fiberglass Insulation Throughout
GE 6 Gal. Gas/Electric DSI Water Heater
Water Heater By-Pass Winterization Kit
12V Demand Water Pump
Premium Exterior Graphics Package
Platinum .024" Aluminum Exterior w/.030 Skirt Metal
Smooth HD Aluminum Radius Front
EZ Lube Axles w/Leaf Spring Suspension
Self Adjusting Brakes
Roto-Cast Holding Tanks
Bumper w/ Drain Hose Carrier and End Caps
19,000 BTU Direct Furnace w/Wall Thermostat
30 Amp Elect. Service w/ 100v 45-Amp Power Covt.
Rugged Pro Black Steel Wheels
Magnetic Hands Free Baggage Door Latches
King Antenna
Smoke Alarm
LP/CO Gas Detector
Fire Extinguisher
Fire Escape Windows
Entrance Door Window
Dead-Bolt Lock on Entry Door
Specialized Dispatch Services (1 YR Roadside Assistance)
Read More
Features
Standard Features
Exterior
Electric Awning w/Multicolor LED Strip & Remote
Black Tank Flush
Battery Disconnect Switch
Siphon 360 Holding Tank Roof Vent
Heavy Duty Standard Tongue Jack
(1)20lb. LP Tanks
LP Quick Connect (N/A 154RBX, 154RDX, 164BHX)
Flush Mount Baggage Doors w/Radius Corners
Diamond Plate Rock Guard
Stabilizer Jacks
G20 Tinted Privacy Windows
Premium JBL Exterior Speakers
Friction Hinge Door
Radius Cornered Fiberglass Entry Door
Exterior 110V G.F.C.I Protected Receptacle
Exterior RG-6 Coax Cabling and Satellite Prep
Rain Gutters with Drip Spouts
MORryde StepAbove Solid Steps (N/A 154RBX, 154RDX, 164BHX)
Rear View Camera Prep
Bottle Openers (Exterior Camp Kitchens)
Pets - "Leash Link" Quick Hookup D-Ring
Universal Solar Prep w/Roof & Chg. Controller Connections & Wiring
Rear Ladder Prep
Exterior Camp Kitchen (184RBS)
Interior
RV-Link 4G LTE Remote Connect, WiFi, Booster, and Extender Prep
One Control Smart RV Tech Monitor Panel (uses LCI OneControl - App)
Premium Audio JBL Aura Cube Multi-Zone Function Media Center
Premium JBL Interior Speaker
GE 10.7 Cu. Ft. 12V Refrigerator (3.3 Cu. Ft. 12V Refrigerator 134BHX, 134RDX, 134RKX, 154RBX, 154RDX, 164BHX)
Seamless Thermofoil Countertops Throughout
Deep Basin Farm Style Sink
High Rise Bullet Style Kitchen Faucet
GE Stainless 2-Burner Cooktop with Metal Back-Lit Knobs
Range Hood
GE Stainless Microwave W/Glass Turn Table
Congoleum Woodplank Linoleum Flooring
4000 Lumin LED Interior Touch Lighting
Jiffy Sofa w/Flip Down Cup Holder/Arm Rest (Per Floorplan)
Murphy Bed Sofa (Per floorplan)
Hard Valance Window Treatments
Pedestal Thermofoil Dinette Table (184BHS)
Under Bench Dinette Storage (Per Floorplan)
12V 14" Bathroom Power Vent Fan
Marine Toilet with Foot Flush
ABS Tub/Shower Surround w/Shelves (N/A 154RBX, 154RDX, 164RBX)
Mirror
Bedroom Surface Mounts USB Ports (Each Night Stand)
Kitchen USB's & Outlets
USB Surface Mounts Near Bunk Beds
Master Bedroom Overhead Shelf
Designer Fitted Master Bed Sheet
Teddy Bear Bunk Mats (Per Floorplan)
Full Lino in Slide-Outs and Bedrooms (Carpetless)
Shower/Coat Hooks
Thomas Payne Theater Seating with Reclining Features (184RBS)
Barstools (154RBX, 184RBS)
Construction & Equipment
Cambered Structural Steel I-Beam Frame
Norco Electromagnetic, Powder Coated Chassis
Full Length Frame Outriggers
5/8" Tongue & Groove StableDeck Flooring
2"x2" Floor Joists on Approximately 12" Centers
4" Floor To Frame Steel Lag Bolts
Darco Subfloor Protective Wrap/Enclosure
Seamless Alpha Roof Membrane with Lifetime Warranty
Cross-Braced Engineered Roof Trusses w/5" Crown
3/8" Fully Decked Walk-On Roof
Screwed Cabinet Construction w/Pocket Bored Lumber Core Stiles
5/8" Plywood Under Bed & Dinette Base
78" Interior Height (6'6")
Norco Cable Slide Out
R-7 Fiberglass Insulation Throughout
GE 6 Gal. Gas/Electric DSI Water Heater
Water Heater By-Pass Winterization Kit
12V Demand Water Pump
Premium Exterior Graphics Package
Platinum .024" Aluminum Exterior w/.030 Skirt Metal
Smooth HD Aluminum Radius Front
EZ Lube Axles w/Leaf Spring Suspension
Self Adjusting Brakes
Roto-Cast Holding Tanks
Bumper w/ Drain Hose Carrier and End Caps
19,000 BTU Direct Furnace w/Wall Thermostat
GE 13,500 BTU Central A/C
30 Amp Elect. Service w/ 100v 45-Amp Power Covt.
Rugged Pro Black Steel Wheels
Magnetic Hands Free Baggage Door Latches
Safety Features
Smoke Alarm
LP/CO Gas Detector
Fire Extinguisher
Fire Escape Windows
Entrance Door Window
Dead-Bolt Lock on Entry Door
Options
7 Cu. Ft. LP Gas/Electric RV Refrigerator w/Reversible Door Inserts (N/A 154RBX, 154RDX, 164BHX)
Peak Performance Solar Package - 30A Controller w/ 200W Panel (N/A 154RBX, 154RDX, 164BHX)
Steel Fold-Down Steps IPO MORryde StepAbove Solid Steps (N/A 154RBX, 154RDX, 164BHX)
Exterior Camp Kitchen (184BHS)
Spare Tire (184BHS, 184RBS)
CSA Standards
See us for a complete list of features and available options!
All standard features and specifications are subject to change.
All warranty info is typically reserved for new units and is subject to specific terms and conditions. See us for more details.
Due to the current environment, our features and options are subject to change due to material availability.
See All Features
